Chimei Kibisan® PN-117H L150FG SAN
Kibisan® PN-117H L150FG Low Residual Monomer Grade SAN
AS(SAN) KIBISAN® PN-117H L150FG is a low residual monomer SAN resin certified for food safety (EU 10/2011, GB4806). With high strength, chemical resistance, and heat stability, it’s engineered for demanding applications like kitchenware and consumer goods.
Typical property data
Physical Properties
- Mass Density: 1.06 g/cm³ (ISO 1183, 23°C)
- Melt Flow Index: 8 mL/10 min (ISO 1133, 220°C × 10 kg)
Mechanical Properties
- Tensile Strength:
- Yield: 74 MPa (ISO 527, 50 mm/min)
- Break: 74 MPa (ISO 527, 50 mm/min)
- Tensile Elongation: 3% (ISO 527, 50 mm/min)
- Flexural Strength: 121 MPa (ISO 178, 2 mm/min)
- Flexural Modulus: 3.6 GPa (ISO 178, 2 mm/min)
- Izod Impact Strength (Notched):
- At 23°C: 3 kJ/m² (ISO 180/1A)
- At -30°C: Not Available
- Charpy Impact Strength (Notched):
- At 23°C: 3 kJ/m² (ISO 179)
- At -30°C: Not Available
Thermal Properties
- Vicat Softening Temperature:
- 50°C/hr; 1 kg: 108°C (ISO 306)
- 50°C/hr; 5 kg: 104°C (ISO 306)
- Heat Distortion Temperature:
- Unannealed: 86°C (ISO 75/A, 1.8 MPa)
- Annealed: 104°C (ISO 75/A, 1.8 MPa)
- Coefficient of Linear Thermal Expansion: 3.6∼3.8×10−53.6 \sim 3.8 \times 10^{-5} (ISO 11359)
Flammability
Flammability Rating: HB (UL-94, 1.5 mm)
Mold Shrinkage
Mold Shrinkage: 0.2–0.7% (ISO 294-4)
Features & Benefits
Low Monomer, Certified Safety
The Low Residual Monomer SAN KIBISAN® PN-117H L150FG meets stringent EU and China food-contact standards, ensuring safe use in water jars and coffee machines. Ideal for health-critical applications.
High Strength, Reliable Durability
Boasting 74 MPa tensile strength and 3.6 GPa flexural modulus, this resin delivers robust structural integrity for load-bearing parts, reducing breakage in high-stress environments.
Heat & Chemical Resistance
With a Vicat softening point of 108°C and resistance to detergents, it withstands boiling water and harsh cleaning agents in appliances like coffee machines.
Use & Applications
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
