Chimei Kibisan® PN-127 L100 SAN
Plastic Granules
Kibisan® PN-127 L100 Injection Molding Heat Resistant
Kibisan PN-127 L100 SAN Resin is a tough, heat-resistant plastic ideal for industrial use. Its natural amber color hides flaws while giving products a clean look. It can withstands 105°C heat. Easy-to-mold (17 ml/10 min melt flow) and low-shrinkage (0.2–0.7%), it ensures precise, durable parts. Boasts 74MPa tensile strength and UL94 HB flammability for safety.
Associated Documents
ISO TDS
ASTM TDS
MSDS
RoHS
SVHC
UL Product iQ
Processing Data
Typical property data
Physical Properties
- Melt Flow Index: 17 ml/10 min (ISO 1133, 220°C × 10 kg)
- Mass Density: 1.06 g/cm³ (ISO 1183, 23°C)
Mechanical Properties
- Tensile Strength (Yield/Break): 74 MPa (ISO 527, 50 mm/min)
- Tensile Elongation: 3% (ISO 527, 50 mm/min)
- Flexural Strength: 105 MPa (ISO 178, 2 mm/min)
- Flexural Modulus: 3.3 GPa (ISO 178, 2 mm/min)
- Izod Impact Strength: 3 KJ/m² at 23°C, Notched (ISO 180/1A)
- Charpy Impact Strength: 2 KJ/m² at 23°C, Notched (ISO 179)
Thermal Properties
- Vicat Softening Temperature: 105°C (ISO 306, 50°C/hr, 1 kg)
- Heat Distortion Temperature:
- 90°C (1.8 MPa, unannealed, ISO 75/A)
- 101°C (1.8 MPa, annealed, ISO 75/A)
- Coefficient of Linear Thermal Expansion: 3.6∼3.8×10−53.6 \sim 3.8 \times 10^{-5} (ISO 11359)
Flammability
UL-94 Rating: HB at 1.5 mm thickness
Mold Shrinkage
0.2% ~ 0.7% (ISO 294-4)
Heat-Resistant for Tough Jobs
It can withstand up to 105°C (Vicat softening), making it ideal for fan blades or electronics in hot environments. Stays rigid without warping.
Strong Yet Lightweight Build
Tensile strength of 74 MPa and flexural strength of 105 MPa handle stress, while 1.06 g/cm³ density keeps parts light and easy to use.
Easy to Mold Precisely
Melt flow of 17 ml/10 min ensures smooth shaping into complex designs. Low shrinkage (0.2–0.7%) reduces defects for crisp, accurate parts every time.
