Chimei Kibisan® PN-127 L150 SAN
Plastic Granules
Kibisan® PN-127 L150 General Purpose Grade High Flowability
KIBISAN PN-127 L150 is a high-performance, transparent blue SAN resin designed for injection molding. With excellent heat resistance, mechanical strength, and dimensional stability, it’s ideal for precision parts in electronics, appliances, and industrial applications.
Typical property data
Physical Properties
- Melt Flow Index: 17 ml/10 min (ISO 1133, 220°C × 10 kg)
- Mass Density: 1.06 g/cm³ (ISO 1183, 23°C)
Mechanical Properties
- Tensile Strength:
- Yield: 74 MPa (ISO 527, 50 mm/min)
- Break: 74 MPa (ISO 527, 50 mm/min)
- Tensile Elongation: 3% (ISO 527, 50 mm/min)
- Flexural Strength: 105 MPa (ISO 178, 2 mm/min)
- Flexural Modulus: 3.3 GPa (ISO 178, 2 mm/min)
- Izod Impact Strength:
- 23°C, Notched: 3 KJ/m² (ISO 180/1A)
- -30°C, Notched: Not available
- Charpy Impact Strength:
- 23°C, Notched: 2 KJ/m² (ISO 179)
- -30°C, Notched: Not available
Thermal Properties
- Vicat Softening Temperature:
- 1 kg: 105°C (ISO 306, 50°C/hr)
- 5 kg: 104°C (ISO 306, 50°C/hr)
- Heat Distortion Temperature:
- Unannealed: 90°C (ISO 75/A, 1.8 MPa)
- Annealed: 101°C (ISO 75/A, 1.8 MPa)
- Coefficient of Linear Thermal Expansion: 3.6 × 10⁻⁵ to 3.8 × 10⁻⁵ (ISO 11359)
Flammability
UL-94: HB (1.5 mm)
Mold Shrinkage
0.2% to 0.7% (ISO 294-4)
Features & Benefits
Exceptional Heat Resistance
With a Vicat softening temperature of 105°C and heat deflection up to 101°C, PN-127 L150 excels in high-temperature environments. Perfect for components like electrical housings or fan blades near heat sources.
Superior Mechanical Strength
Featuring a tensile strength of 74 MPa and flexural modulus of 3.3 GPa, this SAN resin ensures durability and rigidity. Ideal for structural parts requiring long-term reliability.
Precise Moldability
Low mold shrinkage (0.2–0.7%) and a melt flow index of 17 ml/10 min enable fast, accurate molding of intricate designs. Perfect for transparent pen tubing or electronic parts.
Features & Benefits
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
