Chimei Polylac® PA-707 General Purpose Grade

Polylac® PA-707 ABS Resin General Purpose Grade

Chimei POLYLAC PA-707 is a premium General ABS resin designed for high-gloss finishes, ultra-rigid performance, and exceptional durability. Ideal for demanding industrial applications, this POLYLAC ABS grade combines aesthetics with structural integrity, making it a cost-effective choice for components requiring polished surfaces and reliable strength.

Character: High gloss, ultra-high rigidity, especially good tensile strength

ABS Resin

Chimei POLYLAC® ABS Resin

Key technical data

Melt Flow Index: 20 ml/10 min (220°C/10KG)
Tensile Strength: 50 MPa (yield)
Flexural Strength: 79 MPa
Heat Resistance: HDT 98°C (annealed)
Impact Resistance: 13 kJ/m² (23°C, notched)
Flammability: UL94 HB (1.5mm)
Mold Shrinkage: 0.4–0.7%

Download

ISO TDS Download

ASTM TDS Download

MSDS Download

Process Guide Download

UL Product iQ Download

High-Gloss, Scratch-Resistant Finish

POLYLAC PA-707’s mirror-like surface eliminates secondary painting, saving time and costs. Perfect for consumer-facing products like telephone casings or appliance buttons where aesthetics matter.

Ultra-Rigid & Dimensional Stability

With flexural strength of 79 MPa and low mold shrinkage (0.4–0.7%), this resin resists warping, ensuring precision in parts like clock casings or office supplies that require tight tolerances.

Heat & Impact Resilience

Survives harsh conditions: Vicat softening at 104°C and HDT up to 98°C for heat resistance, plus 13 kJ/m² impact strength at 23°C. Ideal for lamp seats near bulbs or toys subjected to rough handling.

Applications

Telephone Casings
Lamp Seats
Toys
Office Supplies
Clock Casings
Appliance Buttons

Polylac® PA-707 Datasheet

General ABS POLYLAC® PA-707 Product Description: High gloss, High rigid
Properties	ISO Test Method	Test Condition	Unit	PA-707
Melt Flow Index	1133	220℃×10KG	ml/10 min	20
Mass Density	1183	23 ℃	g/cm3	1.06
Tensile Strength	527	50 mm/min, yield	MPa	50
Tensile Strength	527	50 mm/min, break	MPa	36
Tensile Elongation	527	50 mm/min	%	40
Flexural Strength	178	2 mm/min	MPa	79
Flexural Modulus	178	2 mm/min	GPa	2.3
Izod Impact Strength	180/1A	23℃, Notched	KJ/m2	13
Izod Impact Strength	180/1A	-30℃, Notched	KJ/m2	7
Charpy Impact Strength	179	23℃, Notched	KJ/m2	14
Charpy Impact Strength	179	-30℃, Notched	KJ/m2	8
Vicat Softening Temp.	306	50℃/hr;1KG	℃	104
Vicat Softening Temp.	306	50℃/hr;5KG	℃	99
Heat Distortion Temp.	75/A	1.8MPa, unannealed	℃	83
Heat Distortion Temp.	75/A	1.8MPa, annealed	℃	98
Coefficient of Linear Thermal Expansion	11359	–	–	8.4 x 10-5
Flammability	–	UL-94	–	1.5mm HB
Mold Shrinkage	294-4	–	%	0.4~0.7
Symbol	1043	–	–	>ABS<
March 12, 2025 Notes：These are typical properties only and are not to be construed as specifications. Users should confirm results by their own test.

Polylac® PA-707 UL Product iQ

POLYLAC® PA-707(+) \| UL Product iQ
File Number: E56070	Yellow Card™	Acrylonitrile Butadiene Styrene (ABS) “POLYLAC”, furnished as pellets
(+) – Indicate 0~0.5% acid scavengers.
FLAMMABILITY PROPERTIES	VALUE	TEST METHOD
Flammability		ANSI/UL 94
1.5 mm, Color: ALL	HB
3.0 mm, Color: ALL	HB
ISO/IEC FLAMMABILITY PROPERTIES	VALUE	TEST METHOD
Flammability		IEC 60695-11-10
1.5 mm, Color: ALL	HB75
3.0 mm, Color: ALL	HB40
ELECTRICAL PROPERTIES	VALUE	TEST METHOD
Hot-wire Ignition (HWI)		UL 746A
1.5 mm	PLC 4
3.0 mm	PLC 4
High Amp Arc Ignition (HAI)		UL 746A
1.5 mm	PLC 0
3.0 mm	PLC 0
Comparative Tracking Index (CTI)	PLC 1	UL 746A
High Voltage Arc Tracking Rate (HVTR)	PLC 2
High Voltage, Low Current Arc Resistance	PLC 6
THERMAL PROPERTIES	VALUE	TEST METHOD
Relative Thermal Index – Electrical Strength		UL 746B
1.5 mm	60 °C
3.0 mm	60 °C
Relative Thermal Index – Mechanical Impact		UL 746B
1.5 mm	60 °C
3.0 mm	60 °C
Relative Thermal Index – Mechanical Strength		UL 746B
1.5 mm	60 °C
3.0 mm	60 °C
