Polylac® PA-756H Ultra High Flow Grade ABS Plastic
POLYLAC PA-756H ABS resin combines ultra-high flowability (80 ml/10 min melt flow) with exceptional strength and thermal stability. Ideal for large or ultra-thin components, this Polylac high flow material ensures precision, durability, and cost-efficiency for automotive, electronics, and industrial applications.
Associated Documents
ISO TDS
ASTM TDS
MSDS
UL Product iQ
Process Guide
Typical property data
Physical Properties
- Melt Flow Index: 80 ml/10 min (ISO 1133, 220℃ × 10kg)
- Mass Density: 1.05 g/cm³ (ISO 1183, 23℃)
Mechanical Properties
- Tensile Strength:
- At yield: 45 MPa (ISO 527, 50 mm/min)
- At break: 33 MPa (ISO 527, 50 mm/min)
- Tensile Elongation: 45% (ISO 527, 50 mm/min)
- Flexural Strength: 65 MPa (ISO 178, 2 mm/min)
- Flexural Modulus: 2.2 GPa (ISO 178, 2 mm/min)
- Izod Impact Strength (Notched):
- At 23℃: 8 KJ/m² (ISO 180/1A)
- At -30℃: 5 KJ/m² (ISO 180/1A)
- Charpy Impact Strength (Notched):
- At 23℃: 9 KJ/m² (ISO 179)
- At -30℃: 5 KJ/m² (ISO 179)
Thermal Properties
- Vicat Softening Temperature:
- 102℃ (ISO 306, 50℃/hr, 1kg)
- 95℃ (ISO 306, 50℃/hr, 5kg)
- Heat Distortion Temperature:
- 82℃ (ISO 75/A, 1.8 MPa, unannealed)
- 97℃ (ISO 75/A, 1.8 MPa, annealed)
- Coefficient of Linear Thermal Expansion: 8.9×10−58.9 \times 10^{-5} (ISO 11359)
Flammability
Flammability Rating: HB (UL-94, 1.5mm)
Mold Shrinkage
Mold Shrinkage: 0.4% ~ 0.7% (ISO 294-4)
property 6
Features & Benefits
Ultra-High Flow Efficiency
POLYLAC PA-756H’s unmatched flowability (80 MFI) fills intricate molds effortlessly, reducing cycle times by 15–20%. Perfect for complex geometries like thin-walled laptop casings or automotive grilles, minimizing warping and material waste.
Strength Meets Impact Resistance
With 45 MPa tensile strength and 8 KJ/m² impact resistance, this Chimei POLYLAC ABS withstands stress and drops. Use it for tool handles, appliance housings, or rugged equipment parts that demand toughness without brittleness.
Heat Resistance for Demanding Environments
Vicat softening at 102°C and heat distortion up to 97°C ensure stability in high-temperature settings. Ideal for under-the-hood automotive components or electronics exposed to heat, preventing deformation during operation.
Use & Applications
- Automotive: Ultra-thin trim panels, large dashboards, and vent housings with zero sink marks.
- Electronics: Slim smartphone frames, lightweight laptop bases, and wearables requiring precise thin-wall molding.
- Appliances: Large refrigerator components or vacuum cleaner bodies needing high flow for seamless finishes.
- Industrial Equipment: Complex connectors and housings where fast cycle times reduce production costs.
