Chimei Polylac® PA-757 A01 ABS
Plastic Granules
Polylac® PA-757 A01 Standard White Color Pre-colored
POLYLAC PA-757 A01, Chimei’s premier White ABS resin, known for its high gloss and medium impact strength. This versatile material is perfect for creating durable and visually appealing products. With excellent mechanical strength, thermal stability, and flame retardancy, it meets the demands of modern manufacturing, offering both performance and aesthetic flexibility.
Associated Documents
ISO TDS
ASTM TDS
MSDS
UL Product iQ
Process Guide
Typical property data
Physical Properties
- Melt Flow Index: 18 ml/10 min (ISO 1133, 220℃ × 10 kg)
- Mass Density: 1.07 g/cm³ (ISO 1183, 23℃)
Mechanical Properties
- Tensile Strength (Yield): 47 MPa (ISO 527, 50 mm/min)
- Tensile Strength (Break): 35 MPa (ISO 527, 50 mm/min)
- Tensile Elongation: 40% (ISO 527, 50 mm/min)
- Flexural Strength: 70 MPa (ISO 178, 2 mm/min)
- Flexural Modulus: 2.4 GPa (ISO 178, 2 mm/min)
- Izod Impact Strength (Notched, 23℃): 17 KJ/m² (ISO 180/1A)
- Charpy Impact Strength (Notched, 23℃): 17 KJ/m² (ISO 179)
Thermal Properties
- Vicat Softening Temperature (1 kg): 106℃ (ISO 306, 50℃/hr)
- Vicat Softening Temperature (5 kg): 99℃ (ISO 306, 50℃/hr)
- Heat Distortion Temperature (Annealed, 1.8 MPa): 98℃ (ISO 75/A)
- Coefficient of Linear Thermal Expansion: 7.9×10−67.9 \times 10^{-6} (ISO 11359)
Flammability
UL-94 Flammability Rating: HB (1.5 mm)
Mold Shrinkage
Mold Shrinkage: 0.4–0.7% (ISO 294-4)
Features & Benefits
Unmatched Rigidity
With a flexural modulus of 2.4 GPa, Chimei ABS Resin PA757 A01 ensures your products maintain their shape and structural integrity, even under significant stress. Ideal for load-bearing components in appliances and equipment, this feature reduces the risk of deformation, saving you time and costs on replacements.
Dependable Impact Resistance
Boasting an Izod impact strength of 17 KJ/m², this White ABS POLYLAC® PA-757 A01 can withstand moderate impacts, making it suitable for products that might be dropped or knocked around, like office printers or cosmetic jars. This durability ensures your products stand up to daily wear and tear, enhancing customer satisfaction.
Striking Aesthetic Finish
The high-gloss surface of POLYLAC PA-757 A01 enhances the visual appeal of your products, while its availability in standard-white and various pre-colored options allows for easy customization to match your brand’s aesthetic. This eliminates the need for secondary finishing processes, streamlining your production workflow.
Use & Applications
- Household Appliances: refrigerators and washing machines
- Cosmetics Containers
- Office Appliances: printers and copiers
