Covestro Makrolon® 6487 PC Resin
Makrolon 6487 PC Resin Flame retardant grades
Makrolon 6487 Polycarbonate Resin by Covestro delivers superior flame retardancy (UL 94V-0/1.5mm & 5VA/3.0mm), medium flow (9.0 cm³/10 min MVR), and UV stability. Ideal for injection molding, it ensures easy release and comes in opaque colors for demanding industrial applications.
Plastic Granules
Download PDF
ISO TDS
Typical property data
Physical Properties (Rheological)
- Melt Volume-Flow Rate (MVR): 9.0 cm³/10 min (300 °C/1.2 kg, ISO 1133)
- Melt Mass-Flow Rate (MFR): 10.0 g/10 min (300 °C/1.2 kg, ISO 1133)
- Molding Shrinkage (Parallel): 0.7% (ISO 294-4)
- Molding Shrinkage (Normal): 0.75% (ISO 294-4)
- Molding Shrinkage (Range): 0.6–0.8% (ISO 2577)
Mechanical Properties (23 °C/50% r.h.)
- Tensile Modulus: 2450 MPa (1 mm/min, ISO 527-1,-2)
- Yield Stress: 66 MPa (50 mm/min, ISO 527-1,-2)
- Yield Strain: 6.0% (50 mm/min, ISO 527-1,-2)
- Flexural Modulus: 2450 MPa (2 mm/min, ISO 178)
- Flexural Strength: 99 MPa (2 mm/min, ISO 178)
- Charpy Notched Impact Strength (23 °C): 70 kJ/m² (3 mm, ISO 21305/ISO 179/1eA)
- Charpy Notched Impact Strength (-30 °C): 12 kJ/m² (3 mm, ISO 21305/ISO 179/1eA)
- Puncture Impact Force (23 °C): 5200 N (ISO 6603-2)
- Puncture Impact Force (-30 °C): 6000 N (ISO 6603-2)
Thermal Properties
- Glass Transition Temperature: 141 °C (10 °C/min, ISO 11357-1,-2)
- Heat Deflection Temperature (HDT) at 1.8 MPa: 122 °C (ISO 75-1,-2)
- Heat Deflection Temperature (HDT) at 0.45 MPa: 134 °C (ISO 75-1,-2)
- Vicat Softening Temperature: 141 °C (50 N, 50 °C/h, ISO 306)
- Coefficient of Linear Thermal Expansion (Parallel/Normal): 0.65 × 10⁻⁴/K (23–55 °C, ISO 11359-1,-2)
- Burning Behavior (1.5 mm): UL 94 V-0
- Burning Behavior (3.0 mm): UL 94 5VA
- Oxygen Index: 36% (ISO 4589-2)
Electrical Properties (23 °C/50% r.h.)
- Relative Permittivity (100 Hz): 3.1 (IEC 60250)
- Relative Permittivity (1 MHz): 3.0 (IEC 60250)
- Dissipation Factor (100 Hz): 0.0008 (IEC 60250)
- Dissipation Factor (1 MHz): 0.009 (IEC 60250)
- Volume Resistivity: 10¹⁴ Ohm·m (IEC 62631-3-1)
- Surface Resistivity: 10¹⁶ Ohm (IEC 62631-3-2)
- Electrical Strength: 34 kV/mm (1 mm, IEC 60243-1)
Other Properties (23 °C)
- Water Absorption (Saturation): 0.30% (ISO 62)
- Water Absorption (Equilibrium): 0.12% (23 °C, 50% r.h., ISO 62)
- Density: 1200 kg/m³ (ISO 1183-1)
- Bulk Density (Pellets): 640 kg/m³ (ISO 60)
Processing and Drying Conditions
- Melt Temperature: 280–320 °C (ISO 294)
- Mold Temperature: 80–120 °C (ISO 294)
- Injection Velocity: 200 mm/s (ISO 294)
- Drying Temperature: 120 °C (Dry Air)
- Drying Time: 2–3 hours
- Maximum Moisture Content: ≤ 0.02%
Use & Applications
- Electrical: Circuit breakers, fuse boxes, connectors (UL/CTI compliant).
- Transport: Aircraft/EV battery covers, dash components (flame-safe).
- Industrial: Machinery housings, safety visors (impact/UV resistant).
- Consumer: Power tool bodies, appliance housings (color-stable).
Features & Benefits
Uncompromised Fire Safety
It achieves UL 94V-0 (1.5mm) and 5VA (3.0mm) ratings, meeting strict flammability standards for electrical/transport components without secondary coatings.
Precision Molding Efficiency
Medium viscosity (MVR 9.0 cm³/10 min) enables complex mold filling, while easy-release properties reduce cycle times and tool maintenance costs.
Enhanced Longevity & Stability
UV stabilization combats environmental degradation, ensuring color/mechanical retention in outdoor enclosures or lighting components.
Makrolon® 6487 Related Flame Retardant Grades
Disclaimer: Grades below are potential alternatives for comparison only. Not direct drop-in replacements. Typical values from Covestro ISO TDS; verify UL94 colors/thickness on current UL Yellow Card. RoHS/REACH/halogen/PFAS status not confirmed unless report provided.
| Grade | Positioning | UL94 (ISO TDS) | MVR | HDT (1.80 MPa) | Notched Impact (23°C/3mm) | Color | UV / UL 746C f1 |
|---|---|---|---|---|---|---|---|
| 6485 | Medium viscosity; 5VA; no UV | V-0 @1.5mm; 5VA @3.0mm | 9.0 cm³/10min | 124°C | Charpy 70P(C); Izod 65P(C) | Opaque | No / N/A |
| 6487 RE | Bio-circular (ISCC PLUS); 5VA; UV | V-0 @1.5mm; 5VA @3.0mm | 9.0 cm³/10min | 122°C | Charpy 70P(C); Izod 70P(C) | Opaque | Yes / N/A |
| 9417 | 10% GF; UV; 5VA | V-0 @1.5mm; 5VA @3.0mm | 6.0 cm³/10min | 135°C | Charpy 10C; Izod 10C | Opaque | Yes / N/A |
| 6557 | Medium viscosity; UV; transparent | V-2 @1.5mm; V-0 @3.0mm | 10 cm³/10min | 124°C | Charpy 70P(C); Izod 65P | T/T/O | Yes / N/A |
👉 Full Portfolio: Browse all 27+ grades on the Covestro Flame Retardant PC Resin Hub.
