Formosa (FCFC) TAIRILITE® AC3900
TAIRILITE® AC3900 PC Resin Self Extinguishing Grade
Tairilite AC3900 is a self-extinguishing, halogen-free PC resin delivering superior flame retardancy (UL94 V-0) and high-impact strength. Its opaque white finish with high-gloss reflection ensures aesthetic versatility for demanding applications like electronics and lighting components.
Plastic Granules
Download PDF
ISO Data Sheet
ASTM Data Sheet
UL Product iQ
MSDS
Processing Data
Typical property data
Physical Properties
- Specific Gravity: 1.28 (ISO 1183, 23℃)
Mechanical Properties
- Tensile Strength: 60 MPa (ISO 527, 23℃)
- Flexural Strength: 104 MPa (ISO 178, 23℃)
- Flexural Modulus: 2350 MPa (ISO 178, 23℃)
- Rockwell Hardness: R-121 (ISO 2039-2, 23℃)
Impact Properties
- IZOD Impact Strength: 585 J/m (ISO 180, 23℃, 3.2mm)
- Charpy Impact Strength: 45 kJ/m² (ISO 179, 23℃, 4mm)
Thermal Properties
- Vicat Softening Point: 146℃ (ISO 306, VICAT 10N ℃)
- Heat Deflection Temperature: 124℃ (ISO 75/A, Unannealed 18.6 kg/cm² [1.8MPa], 3.2mm)
Flame Characteristics
- Combustibility: UL-94 V-0 (1.5–3 mm)
- Halogen Free: Yes
Injection Molding
- Melt Flow Index: 26 g/10 min (ISO 1133, 300℃ × 1.2kg)
- Molding Shrinkage: 0.5–0.7% (ISO 2577, 3.2mm)
Use & applications
Features & Benefits
Halogen-Free Flame Safety
AC3900 achieves UL94 V-0 certification (1.5–3 mm thickness) without toxic halogens, meeting strict eco-regulations while preventing fire propagation in electrical components.
Unmatched Impact Resistance
With 585 J/m Izod impact strength (ISO 180), it withstands drops, vibrations, and mechanical stress—ideal for protective housings and structural parts.
Optimized Processing Versatility
It pre-dries at 120–130°C (4–8 hrs) and processes smoothly at 260–290°C melt temps, ensuring efficient molding with low shrinkage (0.5–0.7%).
FAQs
The supplied ISO TDS lists “Halogen free” in the features.
UL Product iQ lists V-0 at 1.5 mm and 3.0 mm in NC color. The ISO TDS lists V-0 1.5–3.0 mm. If you need a different color, verify whether it is covered by the UL yellow card.
The provided UL excerpt does not list UL 746C f1 for AC3900. For outdoor applications, request the current UL Product iQ page or consider grades with f1 coverage.
It is a white-color, non-transparent grade with high gloss reflection, halogen-free and flame-retardant. It is often chosen for white reflective parts where V-0 is required.
The processing data recommends pre-drying at 120–130°C for 4–8 hr. Screw temperature is 260–290°C, mold temperature 80–100°C, and injection pressure 50–90 kg/cm². Confirm with your actual machine and part geometry.
AC3900 Related Flame Retardant Grades
Disclaimer:Disclaimer: The grades below are potential alternatives for comparison only from FORMOSA (FCFC). They are not direct drop-in replacements. UL ratings are color- and thickness-dependent. Typical values are not specifications. All property data is from ISO TDS unless otherwise stated. Please verify current UL Product iQ status, request TDS/SDS/COA and test samples before substitution.
| Grade / Manufacturer | Positioning vs. AC3900 | UL94 (ISO TDS) | MFR | HDT | Notched Impact (IZOD / Charpy) | Color | UV / UL 746C f1 |
|---|---|---|---|---|---|---|---|
| AC3830 FORMOSA TAIRILITE® PC | Aesthetic/optical sister: light-diffusion FR with UV+f1 for LED diffusers & lampshades | V-0 1.0–3.0 mm; 5VA 3.0 mm | 12 g/10 min | 128 °C | Charpy 70 kJ/m² | Light diffusion; ALL | UL 746C f1; UV resistance |
| AC3610-AF FORMOSA TAIRILITE® PC | Lower-flow non-transparent FR with explicit Cl / Br / Sb-free; broader thickness coverage | V-2 0.6 mm; V-1 0.8 mm; V-0 1.0–3.0 mm; 5VB 2.0–3.0 mm | 10 g/10 min | 113 °C | IZOD 735 J/m | Non-transparency; ALL | / |
| AC3600 FORMOSA TAIRILITE® PC | Non-transparent FR with high heat resistance (HDT 123 °C) for adapters & transformers | V-2 0.6 mm; V-1 0.8 mm; V-0 1.0–3.0 mm; 5VB 2.0–3.0 mm | 11 g/10 min | 123 °C | IZOD 735 J/m; Charpy 65 kJ/m² | Non-transparency; ALL | / |
↩ Back to FORMOSA (FCFC) Flame Retardant PC Resin Hub (13 grades)
Substitution checklist: Before replacing any grade, verify UL94 at the same wall thickness, UL-listed color, halogen-free declaration, MFR/MVR, HDT, notched impact, UV / UL 746C f1 and processing window.
