Chimei Polylac PA-747 High Impact Grade ABS Resin

Polylac® PA-747 High Flow Medium Impact ABS Resin

Polylac PA-747 ABS resin is a high-impact material. It’s built to last in Motorcycle fenders, shoe heels, snow sport products, water filter casings. With top-notch heat resistance and easy molding, it cuts costs and boosts durability. Trusted worldwide, PA-747 handles stress, heat, and heavy use without cracking or warping.

Application: Motorcycle fenders, shoe heels, snow sport products, water filter casings
Character: Ultra-High Impact Strength

ABS Resin

Chimei POLYLAC® ABS Resin

Download

Access essential product documentation including technical data sheets, safety information, environmental certifications, and processing guides. All documents are sourced directly from manufacturers and updated regularly for accuracy.

ISO TDS Download

ASTM TDS Download

MSDS Download

UL Product iQ Download

RoHS Download

REACH SVHC Download

Process Guide Download

Ultra-High Impact Resistance

PA-747 shines in tough conditions. Its Izod impact strength (32 kJ/m² at 23°C) keeps pipes and containers from cracking, even in freezing temperatures (-30°C). Ideal for heavy-duty parts that face bumps or drops daily.

Reliable Heat Resistance

Withstands heat up to 104°C (Vicat) and stays strong under stress (82°C HDT). Safe for appliances near heat sources. Flammability rating (UL94 HB) adds fire safety for worry-free use.

Easy to Process & Mold

Melt flows smoothly (12 ml/10 min) for fast production. Low mold shrinkage (0.4–0.7%) ensures precise shapes. Pre-dry at 80–85°C and mold at 30–70°C for hassle-free results. Saves time and cuts waste.

Polylac® PA-747 Datasheet

General ABS POLYLAC® PA-747
Product Description: High impact
Properties	ISO Test Method	Test Condition	Unit	PA-747
Melt Flow Index	1133	220℃×10KG	ml/10 min	12
Mass Density	1183	23 ℃	g/cm3	1.03
Tensile Strength	527	50 mm/min, yield	MPa	39
Tensile Strength	527	50 mm/min, break	MPa	30
Tensile Elongation	527	50 mm/min	%	35
Flexural Strength	178	2 mm/min	MPa	58
Flexural Modulus	178	2 mm/min	GPa	1.8
Izod Impact Strength	180/1A	23℃, Notched	KJ/m2	32
Izod Impact Strength	180/1A	-30℃, Notched	KJ/m2	23
Charpy Impact Strength	179	23℃, Notched	KJ/m2	33
Charpy Impact Strength	179	-30℃, Notched	KJ/m2	25
Vicat Softening Temp.	306	50℃/hr;1KG	℃	104
Vicat Softening Temp.	306	50℃/hr;5KG	℃	96
Heat Distortion Temp.	75/A	1.8MPa, unannealed	℃	82
Heat Distortion Temp.	75/A	1.8MPa, annealed	℃	97
Coefficient of Linear Thermal Expansion	11359	–	–	9.3 x 10-5
Flammability	–	UL-94	–	1.5mm HB
Mold Shrinkage	294-4	–	%	0.4~0.7
Symbol	1043	–	–	>ABS<
				March 11, 2024

Polylac® PA-747 UL Product iQ

POLYLAC® PA-747(+) UL Product iQ
File Number: E56070	Yellow Card™	Acrylonitrile Butadiene Styrene (ABS) “POLYLAC”, furnished as pellets
(+) – Indicate 0~0.5% acid scavengers.
FLAMMABILITY PROPERTIES	VALUE	TEST METHOD
Flammability		ANSI/UL 94
1.5 mm, Color: ALL	HB
3.0 mm, Color: ALL	HB
ISO/IEC FLAMMABILITY PROPERTIES	VALUE	TEST METHOD
Flammability		IEC 60695-11-10
1.5 mm, Color: ALL	HB75
3.0 mm, Color: ALL	HB40
ELECTRICAL PROPERTIES	VALUE	TEST METHOD
Hot-wire Ignition (HWI)		UL 746A
1.5 mm	PLC 4
3.0 mm	PLC 4
High Amp Arc Ignition (HAI)		UL 746A
1.5 mm	PLC 0
3.0 mm	PLC 0
Comparative Tracking Index (CTI)	PLC 1	UL 746A
High Voltage Arc Tracking Rate (HVTR)	PLC 0
High Voltage, Low Current Arc Resistance	PLC 7
THERMAL PROPERTIES	VALUE	TEST METHOD
Relative Thermal Index – Electrical Strength		UL 746B
1.5 mm	85 °C
3.0 mm	85 °C
Relative Thermal Index – Mechanical Impact		UL 746B
1.5 mm	80 °C
3.0 mm	80 °C
Relative Thermal Index – Mechanical Strength		UL 746B
1.5 mm	85 °C
3.0 mm	85 °C
		Report Date: 1983-06-23
