KIBILAC® PW-904 SUP ASA Pharmacological Medical Use
Chimei KIBILAC® PW-904 SUP ASA resin is a medical-grade material certified for bio-compatibility (ISO 10993), combining durability, heat resistance, and ease of molding. Ideal for medical devices and equipment, it ensures reliability in demanding environments while meeting stringent safety standards.
- Character: Bio-compatibility test (ISO10993)
Applications
- Surgical Instrument Housings: Withstands repeated autoclaving without degradation.
- Diagnostic Equipment Panels: Resists chemicals and maintains clarity for labels/display covers.
- Sterilization Trays: Durable under high-heat cycles and impact during handling.
- Implantable Device Casings: Compliant with ISO 10993 for biocompatibility assurance.
Kibilac® PW-904 SUP Datasheet
| Medical KIBILAC® PW-904_SUP Product Description: ISO 10993 | ||||
| Properties | ISO Test Method | Test Condition | Unit | PW-904_SUP |
| Melt Flow Index | 1133 | 220℃×10KG | ml/10 min | 1133 |
| Mass Density | 1183 | 23 ℃ | g/cm3 | 1.07 |
| Tensile Strength | 527 | 50 mm/min, yield | MPa | 45 |
| 50 mm/min, break | MPa | 33 | ||
| Tensile Elongation | 527 | 50 mm/min | % | 30 |
| Flexural Strength | 178 | 2 mm/min | MPa | 64 |
| Flexural Modulus | 2 mm/min | GPa | 2 | |
| Izod Impact Strength | 180/1A | 23℃, Notched | KJ/m2 | 20 |
| -30℃, Notched | KJ/m2 | 9 | ||
| Charpy Impact Strength | 179 | 23℃, Notched | KJ/m2 | 21 |
| -30℃, Notched | KJ/m2 | 10 | ||
| Vicat Softening Temp. | 306 | 50℃/hr;1KG | ℃ | 108 |
| 50℃/hr;5KG | ℃ | 96 | ||
| Heat Distortion Temp. | 75/A | 1.8MPa, unannealed | ℃ | 80 |
| Coefficient of Linear Thermal Expansion | 11359 | – | – | 9.3×10-5 |
| Flammability | – | UL-94 | – | 1.5mm HB |
| Mold Shrinkage | 294-4 | – | % | 0.4~0.7 |
| Symbol | 1043 | – | – | >ASA< |
| November 2, 2023 Notes：These are typical properties only and are not to be construed as specifications. Users should confirm results by their own test. | ||||
