Chimei Polylac® PA-77NB ABS

By /
Chimei POLYLAC PA-77NB ABS Resin

Polylac® PA-77NB ABS Resin High Heat Grade


Chimei POLYLAC PA-77NB is a high-heat ABS resin engineered for demanding applications. Combining exceptional heat resistance (Vicat 115°C) with low VOC emissions and a low-gloss finish, this POLYLAC® ABS variant ensures durability and compliance for automotive interiors, electronics, and industrial components.

  • Character: Low VOC, heat resistance
contact us
Please enable JavaScript in your browser to complete this form.
Click or drag files to this area to upload. You can upload up to 10 files.
* We prioritize your privacy and ensure information security.

Key technical data

  • Heat Resistance: Vicat 115°C / HDT 106°C
  • Impact Strength: 23 KJ/m² (Izod, 23°C)
  • Tensile Strength: 45 MPa
  • Mold Shrinkage: 0.3–0.6%
  • Flammability: UL94 HB (1.5mm)
  • Density: 1.06 g/cm³

Download

ISO TDSDownload
MSDSDownload
Process GuideDownload
UL Product iQDownload

Exceptional Heat Resistance

With a Vicat softening temperature of 115°C and heat deflection up to 106°C, POLYLAC PA-77NB withstands high-temperature environments, preventing warping in automotive dashboards or under-hood components.

Low VOC & Odor

Ideal for enclosed spaces like car interiors, this High Heat ABS minimizes harmful emissions and odors, meeting strict automotive and electronics industry standards for air quality.

Robust Mechanical Performance

A tensile strength of 45 MPa and impact resistance of 23 KJ/m² ensure durability for snap-fit parts, housings, and structural components exposed to stress or vibration.

Chimei POLYLAC PA-77NB ABS

Applications

  • Automotive Interiors: Dashboard panels, trim components, air vents.
  • Electronics: Housing for routers, power tools, and heat-sensitive devices.
  • Consumer Goods: Appliances requiring low gloss and high dimensional stability.
Chimei POLYLAC PA-77NB application

Polylac® PA-77NB Datasheet

High Heat ABS POLYLAC®  PA-77NB
Product Description: Low emission, Low odour, Low gloss
PropertiesISO Test MethodTest ConditionUnitPA-77NB
Melt Flow Index1133 220℃×10KGml/10 min10
Mass Density1183 23 ℃g/cm31.06
Tensile Strength527 50 mm/min, yieldMPa45
50 mm/min, breakMPa–
Tensile Elongation527 50 mm/min%40
Flexural Strength178 2 mm/minMPa70
Flexural Modulus2 mm/minGPa2.2
Izod Impact Strength180/1A23℃, NotchedKJ/m223
-30℃, NotchedKJ/m2–
Charpy Impact Strength179 23℃, NotchedKJ/m221
-30℃, NotchedKJ/m2–
Vicat Softening Temp.306 50℃/hr;1KG℃115
50℃/hr;5KG℃108
Heat Distortion Temp.75/A1.8MPa, unannealed℃86
1.8MPa, annealed℃106
Coefficient of Linear Thermal Expansion11359 ––8.4 x 10-5
Flammability–UL-94–1.5mm HB
Mold Shrinkage294-4–%0.3~0.6
Symbol1043 ––>ABS<
March  12, 2025
Notes：These are typical properties only and are not to be construed as specifications. Users should confirm results by their own test.

Polylac® PA-77NB UL Product iQ

POLYLAC® PA-77NB | UL Product iQ
File Number: E56070Yellow Card™Acrylonitrile Butadiene Styrene (ABS) “POLYLAC”, furnished as pellets
FLAMMABILITY PROPERTIESVALUETEST METHOD
FlammabilityANSI/UL 94
1.5 mm, Color: ALLHB
3.0 mm, Color: ALLHB
ISO/IEC FLAMMABILITY PROPERTIESVALUETEST METHOD
FlammabilityIEC 60695-11-10
1.5 mm, Color: ALLHB75
3.0 mm, Color: ALLHB40
ELECTRICAL PROPERTIESVALUETEST METHOD
Hot-wire Ignition (HWI)UL 746A
1.5 mmPLC 4
3.0 mmPLC 4
High Amp Arc Ignition (HAI)UL 746A
1.5 mmPLC 1
3.0 mmPLC 1
Comparative Tracking Index (CTI)PLC 2UL 746A
High Voltage Arc Tracking Rate (HVTR)PLC 2
High Voltage, Low Current Arc ResistancePLC 6
THERMAL PROPERTIESVALUETEST METHOD
Relative Thermal Index – Electrical StrengthUL 746B
1.5 mm50   °C
3.0 mm50   °C
Relative Thermal Index – Mechanical ImpactUL 746B
1.5 mm50   °C
3.0 mm50   °C
Relative Thermal Index – Mechanical StrengthUL 746B
1.5 mm50   °C
3.0 mm50   °C

Related Polylac® ABS Plastics

Advanced Manufacturing

Extruder machine
High-speed mixer machine
Water ring pelletizer
Automatic bagging machine
Vibrating screening machine
Plastic rein material warehouse storage capacity
Scroll to Top
