Chimei Polylac® PA-764B Flame Retardant Grade

Polylac® PA-764B Flame Retardant Grade ABS Plastic

CHIMEI POLYLAC® PA-764B is a flame-retardant ABS resin engineered for durability and safety. With UL 94 certifications (2.5mm V-0, 5VB; 3.0mm 5VA), it excels in heat resistance (HDT up to 93°C) and impact strength, ideal for electrical enclosures, automotive components, and appliances. Weather-resistant and UL-compliant, it balances performance with regulatory compliance.

Character Description: Light resistance, heat resistance 2.5mm V-0, 2.5mm 5VB, 3.0mm 5VA

ABS Resin

Chimei POLYLAC® ABS Resin

Key technical data (ISO)

Melt Flow Index: 26 ml/10 min (220°C/10kg)
Flammability: UL 94 V-0 (2.5mm), 5VB (2.5mm), 5VA (3.0mm).
Heat Resistance: HDT 83–93°C (1.8MPa); Vicat Softening Temp: 102°C.
Impact Strength: 14 KJ/m² (Izod, 23°C)
Mold Shrinkage: 0.3–0.6%
Certifications: UL 746A/B, IEC 60695 compliant.

Download

ISO TDS Download

MSDS Download

Process Guide Download

Superior Flame Retardancy

POLYLAC PA-764B meets stringent UL 94 V-0, 5VB, and 5VA standards, ensuring fire safety in thin-walled applications like power panels or electronics housings. Reduces fire risks without compromising structural integrity.

Robust Mechanical Durability

With tensile strength up to 37 MPa and impact resistance (14 KJ/m² at 23°C), it withstands drops, vibrations, and daily wear. Perfect for printer casings, car audio consoles, or industrial equipment.

Reliable Heat Resistance

Vicat softening temperature of 102°C and HDT up to 93°C ensure stability in high-heat environments, such as coffee machines or automotive battery housings. Minimizes warping and deformation.

Applications

Electronics: Modems, power outlets, remote controls, DVD players.
Industrial Equipment: Machine boxes, cash register shells, projectors.
Automotive: Car battery housings, audio consoles.
Appliances: Coffee machines, front/rear TV frames, light boxes.
Office Tech: Printer casings, fax machines, multifunctional peripherals.

Polylac® PA-764B Datasheet

Flame Retardant ABS POLYLAC® PA-764B Product Description: F.R. Weather resistant
Properties	ISO Test Method	Test Condition	Unit	PA-764B
Melt Flow Index	1133	220℃×10KG	ml/10 min	26
Mass Density	1183	23 ℃	g/cm3	1.16
Tensile Strength	527	50 mm/min, yield	MPa	37
Tensile Strength	527	50 mm/min, break	MPa	29
Tensile Elongation	527	50 mm/min	%	15
Flexural Strength	178	2 mm/min	MPa	57
Flexural Modulus	178	2 mm/min	GPa	1.8
Izod Impact Strength	180/1A	23℃, Notched	KJ/m2	14
Izod Impact Strength	180/1A	-30℃, Notched	KJ/m2	7
Charpy Impact Strength	179	23℃, Notched	KJ/m2	14
Charpy Impact Strength	179	-30℃, Notched	KJ/m2	7
Vicat Softening Temp.	306	50℃/hr;1KG	℃	102
Vicat Softening Temp.	306	50℃/hr;5KG	℃	90
Heat Distortion Temp.	75/A	1.8MPa, unannealed	℃	83
Heat Distortion Temp.	75/A	1.8MPa, annealed	℃	93
Coefficient of Linear Thermal Expansion	11359	–	–	8.63 x 10-5
Flammability	–	UL-94	–	2.5mm V-0 2.5mm 5VB 3.0mm 5VA
Mold Shrinkage	294-4	–	%	0.3~0.6
Symbol	1043	–	–	>ABS-FR(17)<
March 12, 2025 Notes：These are typical properties only and are not to be construed as specifications. Users should confirm results by their own test.

Polylac® PA-764B UL Product iQ

POLYLAC® PA-764B(+) \| UL Product iQ
File Number: E56070	Yellow Card™	Acrylonitrile Butadiene Styrene (ABS) “POLYLAC”, furnished as pellets
(+) – Indicate 0~0.5% acid scavengers.
FLAMMABILITY PROPERTIES	VALUE	TEST METHOD
Flammability		ANSI/UL 94
2.5 mm, Color: ALL	5VB, V-0
3.0 mm, Color: ALL	5VA, V-0
ISO/IEC FLAMMABILITY PROPERTIES	VALUE	TEST METHOD
Flammability		IEC 60695-11-10
2.5 mm, Color: ALL	V-0
3.0 mm, Color: ALL	V-0
Flammability		IEC 60695-11-20
2.5 mm, Color: ALL	5VB
3.0 mm, Color: ALL	5VA
ELECTRICAL PROPERTIES	VALUE	TEST METHOD
Hot-wire Ignition (HWI)		UL 746A
2.5 mm	PLC 4
3.0 mm	PLC 3
High Amp Arc Ignition (HAI)		UL 746A
2.5 mm	PLC 0
3.0 mm	PLC 0
Comparative Tracking Index (CTI)	PLC 0	UL 746A
High Voltage Arc Tracking Rate (HVTR)	PLC 2
High Voltage, Low Current Arc Resistance	PLC 7
THERMAL PROPERTIES	VALUE	TEST METHOD
Relative Thermal Index – Electrical Strength		UL 746B
2.5 mm	75 °C
3.0 mm	80 °C
Relative Thermal Index – Mechanical Impact		UL 746B
2.5 mm	80 °C
3.0 mm	80 °C
Relative Thermal Index – Mechanical Strength		UL 746B
2.5 mm	75 °C
3.0 mm	80 °C

Advanced Manufacturing

Plastic rein material warehouse storage capacity
