Chimei Polylac® PA-758 MABS
Plastic Granules
Polylac® PA-758 Transparent High Flow MABS Resin
Polylac PA-758 is a transparent versatile MABS plastic resin with excellent qualities. It’s easy to mold and has good clarity. This material is tough and can handle impacts well. It’s great for making things like air conditioner panels, 3C product casings, and even stationery. The material stays strong in different temperatures. It’s also fire-resistant, meeting UL-94 HB standards at 1.5mm thickness.
Associated Documents
ISO TDS
ASTM TDS
MSDS
RoHS
SVHC
UL Product iQ
Processing Data
Typical property data
Physical Properties
- Melt Flow Index: 3.0 ml/10 min (ISO 1133, 200°C × 5 kg)
- Mass Density: 1.08 g/cm³ (ISO 1183, 23°C)
Mechanical Properties
- Tensile Strength:
- 42 MPa (yield, ISO 527, 50 mm/min)
- 33 MPa (break, ISO 527, 50 mm/min)
- Tensile Elongation: 35% (ISO 527, 50 mm/min)
- Flexural Strength: 57 MPa (ISO 178, 2 mm/min)
- Flexural Modulus: 1.9 GPa (ISO 178, 2 mm/min)
- Izod Impact Strength:
- 14 KJ/m² (ISO 180/1A, 23°C, Notched)
- 7 KJ/m² (ISO 180/1A, -30°C, Notched)
- Charpy Impact Strength:
- 14 KJ/m² (ISO 179, 23°C, Notched)
- 7 KJ/m² (ISO 179, -30°C, Notched)
Thermal Properties
- Vicat Softening Temperature:
- 104°C (50°C/hr; 1 kg, ISO 306)
- 96°C (50°C/hr; 5 kg, ISO 306)
- Heat Distortion Temperature:
- 77°C (1.8 MPa, unannealed, ISO 75/A)
- 97°C (1.8 MPa, annealed, ISO 75/A)
- Coefficient of Linear Thermal Expansion: 9.0 × 10⁻⁵ (ISO 11359)
Flammability
Flammability Rating: HB (UL-94, 1.5 mm)
Mold Shrinkage
Mold Shrinkage: 0.3% ~ 0.7% (ISO 294-4)
Process Guide
- Predrying: 85°C for 3–5 hours, depending on:
- Humidity
- Ratio of regrind
- Storage conditions
- Barrel Temperature Profile:
- Feeding Zone: 200–220°C
- Compression Zone: 220–250°C
- Metering Zone: 220–250°C
- Recommended Processing Temperature: 230–240°C
- Mold Temperature: 50–70°C (depending on part thickness, dimensions, and gating system)
- Injection Pressure: 50–80 kg/cm²
- Holding Pressure: 20–50 kg/cm²
- Back Pressure: 5–10 kg/cm²
- Purging: Use PA-758 resin or high-flow PMMA for purging during shutdown. Avoid using PS, SAN, or other MABS for purging.
Features & Benefits
Clear and Shiny Appearance
Polylac PA-758 offers excellent transparency. It’s perfect for products that need a glossy, crystal-clear look. This resin makes items appear high-quality and attractive.
Easy to Mold and Shape
With high flowability, PA-758 is simple to work with. It fills molds quickly and evenly, allowing for complex shapes and designs in manufacturing processes.
Tough and Impact-Resistant Material
This MABS resin can take a beating. It resists impacts and breaking, making it ideal for durable goods like appliance casings and electronic devices.
